Cummins KT19-M engine
Description
Engine power:425 HP (312 kW)
Number of cylinders:6
Engine type:in-line
Turbo
Fuel:diesel
Euro:2
Condition
Condition:new
Warranty::12 months
Documents
KT19-M425 – General Information
Model: KT19-M425
Type: 6 Cylinders in Line, 4 strokes
Displacement: 19 L
Bore * Stroke: 159 * 159
Net Weight (with flywheel & alternator): 1815 Kg
Overall Dimension: 1666mm*874mm*1377mm
Model: KT19-M425
Type: 6 Cylinders in Line, 4 strokes
Displacement: 19 L
Bore * Stroke: 159 * 159
Net Weight (with flywheel & alternator): 1815 Kg
Overall Dimension: 1666mm*874mm*1377mm
Engine Configuration No.: D192063MX02
KT19-M425 – Performance Data
Rated Power/Speed: 317 kW/425HP
Rated Speed: 1800 rpm
Rating Type: Continuous Running Power
Max Torque/Speed: 1851 N.m @ 1500 rpm
Low Idle Speed: 675-725 rpm
High Idle Speed: 2050-2106 rpm
Fuel Consumption (Running Speed): 79 L/hr
KT19-M425 – Technical Specification
Certification: CCS/IMO Certificates
Aspiration: Turbocharged
Fuel System: Cummins Pressure Time (PT Pump)
Starting System: Electrical Start (24V)
Governor Type: Mechanical Control
Compression Radio: 15.5:1
Lowest Starting Temp Without auxiliary system: -12℃
Cooling Method: Sea water pump, Heat exchanger, Water cooled
